Chemetron Quick Connect Recessed Outlets

(800) 462-8195

Chemetron Quick Connect Recessed Outlets

Web ID: 12496

Condition: Factory New

0 items are in your cart. View cart now.

Need Advice? Ask Our Experts!

(800) 462-8195

Description

  • ETL Listed to UL 1331 and CSA Z9170-1
  • Conforms to NFPA 99 and CGA standards
  • Accepts Allied Chemetron gas specific compatible male adaptors
  • Compensates for variation in wall thicknesses to 1”
  • Gas specific indexing
  • Modular design
  • All outlets are 100% tested for flow and leaks
  • Nameplate color coding per NFPA 99
  • 360 swivel inlet tube
  • Metal back and nameplate
  • 5” centers
  • Made in the U.S.A.

Specifications

General

  • Modular, single quick connect medical gas outlets
  • Color-coded in accordance with NFPA 99
  • Gas services sequentially arranged and located as shown
  • Minimum centerline spacing of 5” (12.5 cm) between outlets
  • Primary check valve can be removed for service without shutting off gas supply
  • Secondary check valve operates automatically to stop the free flow gas
  • No secondary check for Medical Vacuum and WAGD services
  • Double O-ring seal between nameplate and rough-in
  • Seal is serviceable without shutting off the gas service, is capable of supporting 10 lbs. at 2” from the nameplate without leaking
  • Scratch-resistant, durable coating to label and trim
  • Rough-in supply tube measures 7” (18 cm) in length of ½ O.D. copper Type K
  • Service in accordance with current CGA Pamphlet G-4.1
  • To be used in conformance with local and federal codes

Product Options

Oxygen Male Chemetron Quick Connect Recessed Outlets
Medical Air Male Chemetron Quick Connect Recessed Outlets
Nitrous Oxide Male Chemetron Quick Connect Recessed Outlet
Medical Vacuum Male Puritan Bennett Quick Connect Recessed Outlet
Evacuation Male Chemetron Quick Connect Recessed Outlet
