GE Datex-Ohmeda Tec 7 Anesthesia Vaporizer - Refurbished

0

(800) 462-8195

Description

The GE Datex Ohmeda Tec 7 Anesthetic Vaporizer delivers isoflurane, sevoflurane, enflurane and halothane with industry-leading performance and reliability. With unique Easy-fil technology, clinicians can fill anesthetic agents with ease and minimize the chances of leaks. During clinical use, the Tec 7 provides consistent output with a finely-tuned adjustment dial that offers small gradations.

Speak with your DRE representative today to learn more about the GE Datex Ohmeda Tec 7 Anesthetic Vaporizer.

Features

  • Available isoflurane, sevoflurane, enflurane and halothane models.
  • Reliable, high-performing vaporizer designed with ergonomic benefits.
  • Provides consistent agent output: 200 mL/min to 15 L/min.
  • Large, easily manipulated dial adjusts the output with precision.
  • Fine gradations of 0.2% between 0 and 1%, and 0.5% to 1% to 8%.
  • Vaporizer holds 225 mL of anesthetic agent to reduce filling frequency.
  • Factory-service free, eliminating the need for regularly scheduled service.
  • Unique design helps to minimize agent leaks.
  • Two filling options: Easy-fil or Quik-fil (Sevoflurane only).

Specifications

Physical

  • Weight (empty): 15 lbs 6 oz (7 kg)
  • Depth: 8.25 in (210 mm)
  • Width: 4.375 in (110 mm)
  • Height (unlocked position): 9.875 in (250 mm)

Performance

  • Accuracy at 5 liters/min O2 21 ± 2 °C: Vaporizer 5%: ± 0.25% of delivered agent or ± 15% dial setting (whichever is greater), Vaporizer 8%: ± 0.4% of delivered agent or ± 15% dial setting (whichever is greater)
  • Liquid capacity: To fully charge a vaporizer with dry wicks: 300 ml (nominal), Retained by wick system: 75 ml (nominal), To fill minimum to maximum mark: 5% Vaporizer: 170 ml (nominal), 8% Vaporizer (Sevotec): 137 ml (nominal)
  • Flow resistance at 5 liters/minute of O2 at 21 ± 2 °C: 10 - 15 cm H2O with Vaporizer setting ON +0%
  • Operating temperature range: 18 °C to 35 °C (64 °F to 95°F)
  • Storage temperature range: –40 °C to 65 °C (–40 °F to 149°F), Note: Do not let the vaporizer packaging condensate.
