Welch Allyn PIC 30 Monitor / Defibrillator / Pacer - Refurbished
Este producto es muy dificil para encontrar o ya no está disponible de DRE, por favor vea la lista de productos relacionados abajo o pedir su experto de equipos para informacion sobre un producto similar disponible.
0 Los artículos están en tu carrito. Mirar Carrito ya.
¿Necesita asesoramiento sobre los equipos? ¡Pregunte a Nuestros Expertos!
(502) 244-6333
Descripción
The most innovative, reliable monitor/defibrillator/pacer available. The PIC 30 is perfect for crash carts and general patient treatment environments. This easy to use PIC 30 offers quick access controls to promote no-hesitation emergency response. Completely upgradeable, the PIC gives you the flexibility to add functions now or later without having to purchase a new unit. Comprehensive manual defibrillation functions, 3-lead monitoring, patient documentation, optional pacer functions, optional shock advisory and a compact size are combined to deliver a device which is ideal for hospital wards and clinic based emergency care.
Features
- Biphasic technology
- Small (16.7 × 12.5 × 5.3 inches (41.75 × 32 × 13 cm)
- Lightweight (13.5 lbs, 6.1 kg)
- Defibrillator - fast charge to 360 J in less than 7 seconds
- Hands-free defibrillation capability (available)
- Large 6.4 inch (16.5cm) bright, easy-to-read backlit display
- Heart Rate Alarms - user selectable with auto heart rate setting
- Annotating recorder: records date, time, heart rate, ECG lead, size, frequency response - delivered energy
- Comprehensive event log summary
- User replaceable battery with AC back-up power capability
- Shock Advisory (optional)
- External Pacer(optional)
- Also available with monochrome display
Especificaciones
General
- Weight: 13.5 lbs (6.1 kg) (basic configuration).
- Size: 16.7 × 12.5 × 5.3 inches (41.75 × 32 × 13 cm)
- Operating: Time: 2 hours
- Temperature*: 0 to 45°C
- Humidity* (NC): 15 to 95% RH
- Vibration*: MIL-STD 810E
- Shock / Drop*: MIL-STD 810E
- Altitude: Up to 15,000 feet
- Transport and Storage: Temperature (-30 to 70°C), humidity (15 to 95% non-condensing), atmospheric pressure (860 to 1060 hPa), shock/vibration (ISTA 1A)
- Enclosure Protection*:Solid Foreign Object: IEC 529, IP2X
- Water: IEC 529, IPX4.
* All tests performed per AAMI DF-2 Defibrillation Standard.
Operating Power: Battery pack or auxiliary power supply.
Defibrillator
- Biphasic: Low current, impedance compensated, optimized terminating current, truncated exponential biphasic.
- Energy Select:
- External: 2, 5, 7, 10, 20, 30, 50, 70, 100, 150, 200, 300, 360 J
- Internal: 2, 3, 4, 5, 6, 7, 8, 9, 10, 20, 30, 50 J
- Charge Time: < 7 seconds @ 360 J (with a charged battery). < 15 seconds @ 360 J (no battery, 90% AC mains voltage)
- Charge Indicator: Audible and graphic.
- Output: Adult paddles, internal paddles, peds adapter and multipurpose hands-free adapter available.
- Synchronizer: Delivers energy within 60 msec.
- Disarm: Front panel switch.
Power
- Mains Voltage: 100-240VAC (auto ranging)
- Mains Frequency: 50/60Hz
Battery (user replaceable)
- High Capacity Type: NiMH 12 volt - Welch Allyn SuperPac™.
- Low Battery Indicator: Flashing low battery icon on display.
- Multiple Paired Contacts: Ensures quick, error-free insertion and backup reliability.
- Recharge Rate: 80% in 7.5 hours, 100% in 9.5 hours (For high capacity batteries)
Monitor/Display
- Input: 3-lead or 5-lead patient cable, paddles, or multipurpose hands-free adapter.
- Size: 6.4 inch (16.5 cm) diagonal, non-fade.
- Type: LCD Monochromatic
- Display Resolution: 640 x 480 pixels
- Sweep Speed: 25 mm / sec
- Lead Selections: Paddles (Pads), I, II, III, AVR, AVL, AVF, V.
- Frequency Response: (User-selectable) 2 to 20 Hz Limited mode, 0.5 to 40 Hz Monitor mode, 0.05 to 150 Hz.
- Common Mode Rejection: Complies with AAMI EC13-1992 section 3.2.9.10.
- Heart Rate Meter: 20 to 300 BPM
- Heart Rate Alarms: User-selectable
- Size: 0.125, 0.25, 0.5, 1, 2, 4 cm/mv and auto-ranging.
Recorder
- Type: High-resolution thermal array.
- Annotation: Time, date, ECG lead, ECG gain, heart rate, defibrillation and pacing parameters and treatment summary ACLS events.
- Paper Width: 50 mm
- Paper Speed: 25 mm/sec
- Delay: 6 seconds
- Frequency Response: Automatically set to monitor's frequency response.
- Treatment Summary: Records defibrillation, pacing and status events.
- Automatically logs into memory the type of event, time and ECG sample.
- Tx Summary Log: 28 ECG events or 300 non-ECG events.
- Record Modes: Manual and automatic
