Criticare Scholar EL Multi-Parameter Monitor - Refurbished
Este producto es muy dificil para encontrar o ya no está disponible de DRE, por favor vea la lista de productos relacionados abajo o pedir su experto de equipos para informacion sobre un producto similar disponible.
0 Los artículos están en tu carrito. Mirar Carrito ya.
¿Necesita asesoramiento sobre los equipos? ¡Pregunte a Nuestros Expertos!
(502) 244-6333
Descripción
Features
- Up to ten vital parameters in one system with central station capability
- Battery back up
- Interactive, user-friendly data card technology
- ESI suppression, pacer rejection and defibrillator protection
Especificaciones
Physical Weight & Dimensions
- Height: 16.5 cm (6.5 in)
- Width: 34.3 cm (13.5 in)
- Depth: 30.5 cm (12 in)
- Weight: 5.5 Kg (12 lbs) typical
ECG
- Number of Leads: 3 or 5 lead wire cables
- Lead Selection: I, II, III, a VR, aVL, aVF, V (5 wire cable)
- Gain Selection: ½mV, 1mV, 2mV, 4mV, 8mV full scale (all± 2%)
- Frequency Response: Diagnostic: 0.05-100 Hz (-3dB); Monitor: 0.5-40 Hz (-3 dB)
- Sweep Speed: 6.25, 12.5, 25, 50 mm/sec
Heart Rate Display Alarms
- User Selectable Choices: Primary: ECG; Choices: ECG, Pleth, ART, PA, PW
- Range: 20-300 BPM
- Update Time: Every beat
- Accuracy: ± BPM
- Alarm Limit Range: 80-300 BMP (high); 20-150 BPM (low)
Non Invasive Blood Pressure
- Technique: Oscillometric during inflation
- Max Inflation Pressure: Adult 300 mmHg; Neonate: 150mmHg
- Measurement Cycle: <40 second average (0-300 mmHg: adult cuff)
- Automatic Measurement Cycles: 1, 3, 5, 15, 30, 60 minutes
Invasive Blood Pressure (Optional)
- Number of Channels: 4
- User Selectable Labels: ART, PA, ICP, CVP, PW
- Isolation: 4kV RMS, 5.5 kV peak from ground related currents
- Pressure Range: -10 mmHg to 300 mmHg
- Zero Offset: ±150 mmHg
- Probe Impedance: 300-2500 input ohms
- Frequency Response: 0-20 Hz
- Input Impendence: 820K @ 20 Hz; >100M @ DC
- Transducer Sensitivity: 5µV/V/mmHg
- Zero: Auto push button
- Drift: ±1 mmHg
- Accuracy: ±1 mmHg
- Scale Range: -10 to 10, 0 to 20, 0 to 40, 0 to 60, 0 to 100, 0 to 150, 0 to 200, 0 to 300
- Display: Systolic, diastolic, mean pressure
Impendance Respiration
- Rate: 0-150 breaths/minute
- Resolution: 1 breath/minute
- Accuracy: > of ±1% or ±1 breath/minute
Alarms
- Alarm Indication: Audible, visual
- Alarm Silence: Yes (2 minutes, or permanent)
Temperature (Optional)
- Number of Channels: 2
- Range: 20-45° C (68-113° F); ±0.5° C (20-34° C); ±0.2°C (34-41°C); ±0.5°C (41-45°C)
- Display Resolution: 0.1°C or 0.1°F
Oxygen Saturation
- Averaging Time: Selectable 3-21 seconds
- Search Time: Selectable, 1-40 seconds
- Waveform: User selectable
- Gain: User selectable
- Audio: Beep with each detected pulse, pitch varies with oxygen saturation
- Range: 1-99%
- Resolution: 1%
- Accuracy: ±2% (70-99%); ±3% (50-70%)
- High Saturation Alarm: Range: off, 70-99%
- Low Saturation Alarm: Range: off, 1-99%
