Sarns 8000 Heart-Lung Bypass - Refurbished
0 Los artículos están en tu carrito. Mirar Carrito ya.
¿Necesita asesoramiento sobre los equipos? ¡Pregunte a Nuestros Expertos!
(502) 244-6333
Descripción
A flexible, dependable and cost-efficient module blood pumping system.
Features
- Modular design makes a custom system affordable
- Four or five pump base
- Roller or centrifugal pumps
- Arterial and cardioplegia monitors for temperature, pressures and timers
- Battery module
- Electronic venous occluder
- Pulse module
- Communications module for data acquisition
- It is indicated for use in extracorporeal circulation of blood for arterial perfusion, regional perfusion and cardiopulmonary bypass procedures only
Especificaciones
Electrical Power Requirements
- 115 V Bases:
- Voltage - ~103.5-126.5 V
- Frequency - 50/60 Hz
- Circuit Breaker Protection - 16 amps
- Fully Loaded System Current Rating - 4 pump base 13 amps, 5 pump base 15 amps
- 220-240 V Bases:
- Voltage - ~1198-264 V
- Frequency - 50/60 Hz
- Circuit Breaker Protection - 8 amps
- Fully Loaded System Current Rating - 4 pump base 6 amps, 5 pump base 7 amps
- 100 V Bases:
- Voltage - ~90-110 V
- Frequency - 50/60 Hz
- Circuit Breaker Protection - 16 amps
- Fully Loaded System Current Rating - 4 pump base 14 amps, 5 pump base 16 amps
Electrical Power Performance
- Leakage Current: <100 microamperes for 115 V and 100 V bases (fully loaded); <200 microamperes for 22-240 V bases (fully loaded). The maximum leakage current for the base without pumps is 45 microamperes for all input voltages
- Ground Resistance: 0.1 ohms maximum for all bases.
- Emergency Power: 8000 system battery (two 12 volt, sealed gel cell batteries) will power the arterial pump (operating in continuous mode), the monitors, occluder and lamp for 40 minutes; when the arterial pump is operated in pulsatile mode or the cardioplegia pump is also operating on battery power, the battery time available will diminish to 25 minutes. the base is test for high potential: 1200V ~ for 100-1115 VAC units; 1500V ~ for 220-240 VAC units.
Physical Characteristics
- 4 Pumps Unit:
- Height: 25.8" (65.5 cm)
- Width: 33.3" (84.5 cm)
- Depth: 26.5" (67.3 cm)
- Weight: 330 lbs (149.5 kg)
- 5 Pumps Unit:
- Height: 258" (65.5 cm)
- Width: 41.6" (105.6 cm)
- Depth: 26.5" (67.3 cm)
- Weight: 380 lbs (172.1 kg)
- Pump/Roller:
- Height: 14" (35.6 cm)
- Width: 8.2" (20.8 cm)
- Depth: 19.7" (50 cm)
- Weight: 50 lbs (22.6 kg)
- Telescope Pole: 1.30" (3.3 cm) diameter; 6-7 feet (1.8-1.9 m) height
