EspañolMidmark IQecg - Refurbished
Midmark IQecg - Refurbished
This product is either very difficult to find or no longer available through DRE, please see the list of related items to the right or ask your equipment expert for advice on a similar available product.
0 items are in your cart. View cart now.
Need Advice? Ask Our Experts!
(800) 462-8195
Description
The Midmark IQecg makes your job easier with a range of reviewing and editing tools to help increase productivity and efficiency. At the touch of a button, you can capture an abnormal ECG as it appears on screen, enhance the diagnosis with tools like zoom and electronic calipers, quickly edit statements and perform serial comparison.
Features
- Lightweight, portable design, weighing less than 11 oz.
- View and monitor live, 12-lead ECG in selectable formats on screen
- Interpret and analyze data for neonate, pediatric and adult patients via the Midmark 12-lead Resting Electrocardiogram Analysis Program
- Review and edit ECG results on-screen with free text or customizable quick edit statements
- Perform serial comparison with overlay of up to 4 ECG tests
- Save time and reduce data entry errors by populating patient information directly using your EHR/EMR software
- Facilitate paperless office strategy-eliminate costs of thermal paper and the hassles of scanning and filing patient charts
- Intuitive user interface: Quick to learn, easy to use
- Preview and monitor: Real-time 12-lead ECG
- Acquire and store: 10 seconds of 12-lead ECG with auto-interpretation and measurements with one mouse click
- Interpretation: Provided by Midmark 12-lead Resting Electrocardiogram Analysis Program for adult and pediatric patients
- Review and Edit: On screen with zoom, electronic calipers, free text and customizable quick edit statements
- Serial comparison With overlay of up to 4 ECG tests
- Store 55,000 ECG in 1GB of hard-drive space
- EMR/EHR Field proven seamless integration with more than 80 EMR/EHRs
- Warranty 12 months on ECG, 90 days on patient cable
- Patient Connection: 10-lead patient cable with RFI filter, defibrillator protection and patient isolation
- Safety Parameters
- Patient leakage current not to exceed 10uA
- Ground leakage current no to exceed 50uA
- Patient electrically isolated of main current supply
Specifications
General
- Weight 10.2 oz.
- Dimensions 3.5 in. (88mm) × 5.7 in. (175mm) × 1.2 in. (30mm) (W × L × H)
- Power: No batteries required
- ECG Acquisition
- Impedance: >100 megohms
- Frequency response: 0.05-150Hz-3dB
- Filters: AC, drift, muscle
- Sensitivity: 5, 10, 20mm/mV
- Dynamic range: ± 10mV
- ADC resolution: 13 bits at 2.44uV/bit
- Electrode offset: ± 300mV per AAMI and EC-11 specifications
- Acquisition rate: 500 samples/sec
