Oakworks CFPM301 3-Motion Imaging Table
0 items are in your cart. View cart now.
Need Advice? Ask Our Experts!
(800) 462-8195
Description
The Oakworks CFPM301 is a 3-movement imaging table with a dynamic height range of 25" to 43".
Features
- 3 Powered Motions
- Motions: Height, Trendelenburg tilt, Longitudinal travel
- Patient Weight Capacity: 500 lbs (227 kg)
- Industry's widest adjustable height range of 18" (46 cm) - 25" to 43" (63 cm to 109 cm)
- +15/-11° Trendelenburg tilt
- 10" longitudinal travel
- 22" × 84" (56 cm × 213 cm) integrated headrest top
- 56" (142 cm) of metal free imaging area
- 4 Year Warranty
Specifications
General
- Patient Weight Capacity: 500 lbs. (Bariatric version available with 750-pound capacity)
- Optional Integrated Headrest Carbon Fiber Top 22"W × 84"L
- Rectangular Carbon Fiber Top 24"W × 80"L (60 cm × 203 cm)
- Warranty: 4 years parts, 1 year labor
- Certifications: FDA listed, cETL approved, CE marked
- Patient Safety Strap
- 4" Casters
- Hand Control (all motions)
- Foot Control (all motions)
- 1" Radiolucent Table Top Pad
- 3 Cranial Positioning Pads (included with Integrated Headrest Top only)
- (1) 2" thick × 12" square (5 cm × 30 cm)
- (1) 4" thick × 12" square (10 cm by 30 cm)
- (1) Crescent face rest pad
- Motion 1: Height range 25" - 43" (63 cm to 109 cm)
- Motion 2: Trendelenburg tilt +15°/-11°
- Motion 3: 10" longitudinal travel
